Comprehensive TRL assessment, tracking, and reference tool for emerging space technologies
High-specific-impulse electric thrusters that ionize and electrostatically accelerate propellant. Flight-proven on Deep Space 1 (1998), Dawn (2007), and BepiColombo. Provide efficient delta-v for deep-space and station-keeping applications.
Vertically-landing orbital-class rocket boosters that can be reflown dozens of times. SpaceX Falcon 9 has demonstrated over 300 booster landings. Starship super-heavy booster caught by tower arms. Dramatically reduces launch cost per kilogram.
Hall-effect thrusters use magnetic fields to trap electrons and create an electric field that accelerates ions. Widely deployed on commercial satellites (Starlink, OneWeb) and deep-space missions. Operating at 1-50 kW power levels.
Miniaturized propulsion systems for CubeSats and small satellites including cold gas, electrospray, pulsed plasma, and water-based systems. Multiple vendors offering flight-qualified modules in 1U-3U form factors.
Free-space optical links using modulated laser beams to achieve 10-100x higher data rates than RF. NASA LCRD demonstrated 1.2 Gbps from GEO and is operational. DSOC pushing laser comms to deep space (Psyche mission).
Laser-based communication links between satellites in orbit, enabling high-bandwidth mesh networking without ground relay. Starlink V2 satellites include laser inter-satellite links, connecting thousands of spacecraft.
Additive manufacturing in microgravity for producing spare parts, tools, and structural components on-demand. Redwire (formerly Made In Space) has operated multiple 3D printers on ISS since 2014, printing tools, medical devices, and structural parts.
Soft-goods habitat structures that launch compactly and expand on-orbit to provide large pressurized volumes. Bigelow Expandable Activity Module (BEAM) has been attached to ISS since 2016, exceeding its original 2-year demo period.
Spacecraft that rendezvous with, dock to, and extend the life of existing satellites through refueling, repair, or relocation. Northrop Grumman MEV-1 and MEV-2 successfully docked with and extended the life of Intelsat GEO satellites.
Compact nuclear fission reactors producing 1-40 kW of electrical power for lunar and Mars surface operations. NASA Kilopower/KRUSTY test demonstrated full-power Stirling-based system. Selected for Artemis lunar surface power.
Store-and-forward networking protocol suite designed for space environments where continuous connectivity is impossible. Implements Bundle Protocol for interplanetary internet.
Machine learning systems for on-board satellite data processing, autonomous anomaly detection, and mission planning. Planet Labs uses on-board ML for cloud detection and image classification. ESA experimenting with autonomous operations.
Spacecraft autonomously determining position and trajectory using star trackers, terrain-relative navigation, and pulsar-based timing. NASA OSIRIS-REx used autonomous NavCam to navigate to asteroid Bennu. DART mission used autonomous targeting.
Spacecraft designed to rendezvous with and remove orbital debris. Astroscale ADRAS-J mission successfully demonstrated proximity operations with a spent rocket upper stage in 2024, capturing detailed images from close range.
Conductive tethers that interact with Earth's magnetic field to generate thrust or drag without propellant. Demonstrated on TSS-1R (1996) and multiple sounding rocket experiments. Potential for propellantless orbit raising and de-orbit.
Leveraging microgravity for producing higher-purity materials. Varda Space Industries successfully returned a capsule with space-manufactured pharmaceuticals. ZBLAN fiber produced in space shows superior optical properties.
Extracting oxygen from Martian atmospheric CO2 for propellant and life support. NASA MOXIE instrument on Perseverance rover successfully produced oxygen from Mars atmosphere 16 times during its operational period.
Environmental Control and Life Support Systems recovering >98% of water and oxygen from crew metabolic waste. Builds on ISS ECLSS which achieves approximately 90% water recovery. Mars missions require near-complete closure.
Uses a nuclear fission reactor to heat hydrogen propellant, achieving roughly twice the specific impulse of chemical rockets. DARPA DRACO program aims for in-space demonstration by 2027. Enables faster crewed Mars transits by cutting travel time from 9 months to approximately 4.
All-solid-state lithium batteries offering higher energy density, wider temperature range, and improved safety over liquid electrolyte cells. Critical for EVA suits, rovers, and small spacecraft.
Distributes quantum-encrypted keys via satellite using entangled photon pairs. China's Micius satellite demonstrated QKD over 1,200 km. Enables theoretically unbreakable encryption for space networks.
Distributed AI algorithms enabling dozens to hundreds of small satellites to self-organize for coordinated observation, communication relay, or formation flying without centralized control.
Multi-layer composites incorporating hydrogen-rich polymers, boron nitride nanotubes, and regolith-derived ceramics for deep-space habitat protection against galactic cosmic rays and solar particle events.
Continuously detonates fuel in a rotating wave inside an annular chamber, achieving higher thermodynamic efficiency than deflagration combustion. Promises 25% fuel savings over traditional engines.
Collects solar energy in orbit using massive arrays and beams it to Earth via microwave or laser. Caltech SSPD-1 / MAPLE experiment demonstrated wireless power transfer from orbit in 2023. Continuous power generation unaffected by weather or night.
Extracting water ice and minerals from lunar regolith for propellant, construction, and life support. NASA ISRU experiments, VIPER rover mission, and commercial lunar landers are advancing this capability.
Uses concentrated solar energy or microwave sintering to fuse lunar regolith into structural blocks, roads, and landing pads. Reduces Earth-launched construction mass by up to 90%. ICON and AI SpaceFactory leading terrestrial simulant tests.
Short-radius centrifuge systems providing intermittent or continuous partial gravity to counter bone loss, muscle atrophy, and fluid shift effects during long-duration spaceflight.
